WinMLS stores its settings in several files found under different sub-directories of the WinMLS folder as shown below.
The two diagrams below is using these WinMLS sub-directories.
The diagram below shows he files used by WinMLS for obtaining the settings for performing a measurement and the Measurement Panel toolbar that can be used for quickly saving a measurement.
Figure 7 Software file structure for obtaining a measurement.
The diagram below shows the files used by the software for post-processing and plotting measurement data.
Figure 8 Software file structure for post-processing and plotting a measurement.
